E55
A 55-foot electric catamaran combining clean propulsion, battery storage, solar support and generous onboard living for quieter cruising and extended time at sea.
Experience E55
Electric cruising, open deck living and a calm onboard atmosphere.
Quiet propulsion, open-air living.
The E55 brochure presents a 55-foot electric catamaran built around twin electric propulsion, lithium battery storage and solar-assisted onboard energy. The wide catamaran platform supports relaxed cruising and generous outdoor living.
A full-size living platform.
The brochure shows an open main-deck salon, integrated galley and private lower-deck accommodation. The layout drawings and interior photography are used as the reference for the onboard arrangement shown here.
An integrated electric propulsion platform.
The uploaded E55 brochure specifies twin 150 kW electric motors, 220 kWh LFP battery banks, a 75 kW Danfoss diesel generator as a range extender and a 20 kW shore-power charger. The same brochure also states a 1300 L diesel tank dedicated to the generator and a 10 KWH solar system.
A broad catamaran platform arranged for life aboard.
The E55 brochure includes flybridge, main-deck and lower-deck layout drawings that define the reference arrangement used on this page. No website-only accommodation figures are used as product specifications.
E55 specifications
All published product parameters on this page are taken from the uploaded E55 PDF brochure. Corporate website figures are not used as the specification authority because website data may lag product documentation. Final build specification is confirmed at quotation.
Dimensions
- Length overall
- 16.7 m
- Waterline length
- 15.91 m
- Beam
- 8.4 m
- Draft
- 0.98 m
- Bridgedeck height
- 1.00 m
- Height overall
- 4.35 m
- Light displacement
- 26.5 tons
Electric Propulsion
- Electric motors
- 2 × 150 kW
- LFP battery banks
- 220 kWh
- Range-extender generator
- 1 × 75 kW Danfoss diesel
- Shore-power charger
- 20 kW
Tankage, Solar & Performance
- Fuel capacity
- 1300 L
- Fresh water capacity
- 800 L
- Solar system
- 10 KWH — as stated in brochure
- Cruising speed
- 6–8 kn
- Maximum speed
- 13 kn
Optional Hybrid Configuration — Brochure
- Diesel engines
- 2 × 400 hp
- E-motion electric motors
- 2 × 145 kW
- Potential top speed
- Could reach 20 kn — brochure wording
Request the full E55 configuration.
Tell us your intended cruising area, preferred accommodation plan and equipment requirements. MONTARIN will confirm the appropriate build specification and commercial proposal.
